RISER BOX MULTI TRAY (RBMT)
Part Number
XCPSC01221 / XCPSC01159
Max Fiber capacity
32 (RBMT4), 64 (RBMT8)
Max diameter of in line cable
15mm
Max diameter of drop cables
5mm
Features and Benefits
• Allows splicing from in line or butt cables to customer drop cables.
• Suitable for two butt or one inline cable of up to 15mm in diameter
• In line cables can enter/exit from the unit on the left or right hand side.
• 24 drop cables (OD 5 mm) or 32 drop cables (OD 4.2 mm) can bespliced. Drop cables exit the unit from the bottom face.
• The drop cable entries are suitable for cables or tubes from 2.5 to 5 mmin diameter.
• Available in two sizes – RBMT4 with 4 trays and a module storagesection, or RBMT8 with 8 trays.
• Up to 8 fusion splices or 4 mechanical splices can be accommodated intoeach of the splice trays (total of 64 fusion or 32 mechanical splices forthe RBMT8 and 32 fusion or 16 mechanical splices for the RBMT4).
• Can accommodate optical splitters. Contact Prysmian for further details.
• It’s possible to re-launch a cable (OD up to 15 mm) from the bottomface.
• The Storage Area can accept up to 25m of 0.9mm fibre modules.
• Cable management ensures a 20mm minimum bend radius.
• Easily installed and fitted to the wall or inside a riser. Suitable for internaluse only and manufactured from UL94-V0 rated material.
• Input and output cables are retained using cable ties.
| No of Splice Trays: | 4 (RBMT4), 8 (RBMT8) |
| Max capacity | (fibers) 32 (RBMT4), 64 (RBMT8) |
| Max diameter of in line cable: | 15mm |
| Max number of drop cables: | 24 (32 optional with smaller drop cables) |
| Max diameter of drop cables: | 5mm |
| Required space envelope (mm): | (h) 176 x (w) 130 x (d)60 |
| Operating temperature: | -20oC to + 60oC (5 to 95% RH) |
| Material: | FR ABS |
| Color: | White RAL 9016 |
| Flammability rating: | UL94-V0 |
