DS63S AUTOMATIC TWIN LINE BELLING MACHINE
Minimum Size
20 MM
Maximum Size
63 MM
Model
DS63S
standard
U-PVC1002.1-2006 (as request)
Heating method
Four heating ovens
Length
3m - 6m
| Pipe standards | |
| Model | DS63S |
| standard | U-PVC1002.1-2006 (as request) |
| Diameter | 20mm - 63mm |
| Length | 3m - 6m |
| Heating | |
| Heating method | Four heating ovens |
| Electrical | |
| PLC and Screen | Siemens |
| low-voltage apparatus | Schneider, Omron |
| Total Power | 7KW |
| Pneumatic | Compressed air pressure: 0.6Mpa |
| Equipment appearance | |
| Machine type | Automatic, double line, two pipes per cycle |
| Machine dimension | 7500mm(L)×1850mm(W)×1500mm(H) |
| Machine weight | 2200kg |
| Operating principle | |
| U-type | PUSHING THE MOULD DIRECTLY INTO PIPE |
| Cooling type | Air - cooling |
| Machine speed | 22S/ two pipes to 45S/ two pipes |
