DS1200 BELLING MACHINE
DS1200 Belling machine is mainly used for PVC pipes with Solvent type (U-type) and Rubber ring type (R-type). It can work with pipe extrusion line. This machine is fully automatic and easy to operate, according to CE standard.
| Pipe standards | |
| Model | DS1200 |
| standard | U-PVC pipes |
| Diameter | 630mm - 1200mm |
| Pipe Length | 6m |
| Heating | |
| Heating way | 1 oven (Option: 2 ovens) |
| Stainless steel body, long service life | |
| Pipe Rotary | Clockwise and anti-clockwise |
| Electrical | |
| PLC and Screen | Siemens |
| low-voltage apparatus | Schneider, Omron |
| Total Power | 80KW |
| Pneumatic | Compressed air pressure: 0.6Mpa |
| Water | Water pressure: 0.4Mpa |
| Hydraulic | Hydraulic pressure: 8.0Mpa |
| Equipment appearance | |
| Machine type | Automatic, single line, one pipes per cycle |
| Machine dimension | 10000mm(L)×5150mm(W)×3000mm(H) |
| Machine weight | 17000kg |
| Operating principle | |
| U-type | Pushing the mould into pipe directly |
| R-type | With ext - pressure and collapsible mandrel |
| Cooling type | Water – cooling |
| Machine speed | Max. 1200S/pipe |
